    FR24-MS101Pro


















    FR24-MS101Pro


    Radar sensor module 24G motion and micro-motion detection The radar module works in 24G frequency band, uses FMCW frequency modulation continuous wave, detects the target in the set space, combines the radar signal processing, the correct human body induction algorithm, and realizes the high-sensitivity human existence state Sensing and recognizing the human body in motion and static state. Integrated software and hardware solutions such as chips, systems, software, and algorithms.














    Features



     5.8G: Integrated high-performance 32-bit MCU, a single chip directly outputs sensing control signals, a real SoC. Powerful performance, rich algorithms can be used, strong scalability, suitable for high-performance scenarios. It supports a standard UART interface, which can be interconnected with other main controllers or sensors, and can also be used as a main control. It can realize presence sensing based on the detection of human breathing.




     24G: The working frequency of this radar module is 24G, using FMCW continuous wave to detect targets in the set space, combining with radar signal processing and correct human body sensing algorithms, to achieve high-sensitivity sensing of human presence, identifying motion and static states Under the human body. Integrated software and hardware solutions such as chips, systems, software, and algorithms.












    Application scenarios











    Product parameter














                model


                FR58L4M32-2020S/4020S


                model


                FR24-MS101/pro


                FR24-MS201






                Power frequency


                5.8GHz±75MHz


                Power frequency


                24~ 24.25GHz


                24~ 24.25 GHz






                With MCU


                32 bit


                With MCU


                Onboard MCU


                Onboard MCU






                Supply voltage


                4.5-5.5V


                Supply voltage


                3.0~3.6V


                3.0~3.6V






                Power consumption


                20MA


                Power consumption


                ＜50mA


                35mA






                Beam angle


                120°


                Radiated power


                15dBm (typical value)


                14dBm (typical value)






                PCB process


                Ordinary four-layer board


                Modulation


                FMCW


                FMCW






                Communication Interface


                UART


                Hardware size


                18*15mm


                18*15mm






                output signal


                High and low level signal


                Sensing distance


                20 meters


                5 meters (presence induction)






                Forward distance


                1.5M


                Ambient temperature


                -40℃~85℃


                -40℃~85℃
